| 型号 | 尺寸(英寸) | 分辨率 | 长宽比 | 背光亮度(cd/m2) | 视角 | 接口 | 控制器 | 触摸屏 | 有效显示区域 | 外形尺寸 |
| WT015-01 | 1.54 | 240*240 | 1:1 | 200 | full | SPI | ST7789V | / | 27.72*27.72 | 3*2.51.52*35.1*2 |
| WT017-04 | 1.77 | 128*160 | 4:5 | 250 | 6:00 | MCU | ST7735S | / | 28.03*35.04 | 34.7*46.7*2.5 |
| WT020-01 | 2.0 | 320*240 | 4:3 | 250 | 12:00 | RGB | ILI9342C | / | 40.8*30.6 | 46.1*40.96*2.53 |
| WT020-02 | 2.0 | 240*320 | 3:4 | 230 | 6:00 | MCU | ILI9341V | / | 30.6*40.8 | 37.88*51.5*2.5 |
| WT023-01 | 2.3 | 320*240 | 4:3 | 250 | 12:00 | RGB/MCU | ILI9342C | / | 35.06*46.75 | 47.55*55.2*2.8 |
| WT024-03 | 2.4 | 240*320 | 3:4 | 300 | 12:00 | SPI | ST7789V | / | 36.72*48.96 | 42.72*60.26*2.3 |
| WT024-04 | 2.4 | 240*320 | 3:4 | 200 | 6:00 | SPI | ST7789V | RTP | 36.72*48.96 | 42.72*60.26*3.5 |
| WT024-05 | 2.4 | 240*320 | 3:4 | 200 | full | SPI | ST7789V | / | 36.72*48.96 | 42.72*59.2*2.3 |
| WT024-06 | 2.4 | 240*320 | 3:4 | 400 | full | SPI | ST7789V | / | 36.72*48.96 | 42.72*59.2*2.3 |
| WT024-07 | 2.4 | 240*320 | 3:4 | 300 | 6:00 | MCU | ILI9341V | / | 36.72*48.96 | 42.72*60.26*2.3 |
| WT028-04 | 2.8 | 240*320 | 3:4 | 250 | 6:00 | RGB | ST7789V | CTP | 43.2*57.6 | 50*69.2*3.7 |
| WT028-05 | 2.8 | 240*320 | 3:4 | 350 | full | SPI/MCU/RGB | ST7789V | / | 43.2*57.6 | 47.6*64.86*2.1 |
